Atlas Copco Air Compressors
Atlas Copco based in the UK manages the sales, service and industrial gas and air compressors, dryers and filters, compressor parts & service and vacuum pumps. Atlas Copco also caters for construction and demolition machines including mobile compressors, pumps, light towers, generators, excavator attachments, handheld tools, compaction and road construction equipment. Alongside an extensive range of pneumatic grinders, sanders, drills, chipping hammers and riveting systems, and mining and rock excavation equipment.
LE oil-lubricated for single-stage compression
The single-stage oil-lubricated reciprocating compressor allows filtered air to enter both cylinders through the inlet valve. The piston is driven forward through the connection rod attached to the balanced crankshaft. Maximum operating pressure is 10 bar (145psi) and capacities range from 3.4 up to 31.7 l/s at 50 Hz, 8.3 to 79.8 cfm at 60 Hz. Air compressed in the cylinders leaves through the outlet valve when the pressure reaches 10 bar (145psi).
LT oil-lubricated for two-stage compression
The LT two-stage oil-lubricated reciprocating compressor allows filtered air to enter only one cylinder. This low pressure cylinder feeds the second (high pressure) cylinder that can operate at a maximum pressure of 15, 20 or 30 bar (218, 290 or 435 psi) and with the following capacities:
• 15 bar (218 psi)
from 3.1 to 11.7 l/s at 50 Hz, 7.6 to 23.1 cfm at 60 Hz.
• 20 bar (290 psi)
from 2.1 to 18.0 l/s at 50 Hz, 5.7 to 44.3 cfm at 60 Hz.
• 30 bar (435 psi)
from 2.5 to 17 l/s at 50 Hz, 6.6 to 41.7 cfm at 60 Hz.
AF High grade aluminum piston compressors
Our range of AF aluminum piston compressors are all designed for mobility and ease of use. The compressor block is manufactured from high-grade aluminum alloy – the same material used in high-performance car engines. This ensures exceptional heat transfer capabilities and high tensile strength.
AC Belt drive Piston compressors
Designed with a slow-running compressor block for long service life, our AC belt drive cast iron piston compressors provides a solid source of compressed air with a high durability. We also provide aftercoolers and an automotive dry paper type air cleaner on the larger models, providing clean air for your needs.
Easy maintenance
Every Atlas Copco LS and LP is a product of designed excellence with 2-piece connecting rods and oil pressure gauge. The LS and LP are ideal for industrial, automotive and commercial applications requiring up to 175 PSIG. With cast iron construction and industrial class bearings our LS & LP compressors guarantee longevity and durability even during the most demanding environments.
LS cast iron compressor in detail
Our LS is designed with a stainless steel valve design which brings the highest volumetric efficiency on the market. The one-piece aluminum head ensures heat dissipation for high performance.
LP cast iron compressor in detail
The LP high pressure compressor delivers top performance thanks to its industrial class bearings and oversized oil reservoir for low oil temperatures.
Our fully qualified staff are F Gas Certificated, Refcom FGas Certificate and have City & Guilds Level 3 Certificate In The Requirements For Electrical Installations
Written Schemes Of Examination
Under the Pressure Systems Safety Regulations 2000, users and owners of pressure systems need to show that they understand the safe working limits (especially pressure and temperature) of their operations and that they are safe following these conditions.
There is definitely a health hazard for the user if they are breathing contaminated air. Failure to mitigate this risk can result in immediate as well as long-term health problems such as carbon monoxide poisoning, industrial asthma, and chronic obstructive pulmonary disease.
The EQO range of aluminum tube and stainless steel pipe system products, which are practical, versatile, and cost-effective, deliver sophisticated solutions for the distribution of compressed air and industrial fluids.
Why choose Hydropayne Services Air Compressors Kent? We aim to provide flexible solutions tailored to your specific business requirements. We provide a professional, cost effective service, keeping down-time to a minimum by carrying out all work on-site where possible.
Compressor system maintenance and repair experts in Kent Hydropayne Services highly trained engineers work closely with you to provide comprehensive wide range of compressed air systems repairs and maintenance, including all pipework and electrical work.
